1. Since the beginning of the industrial tumble dryer, the proportion of energy consumption and efficiency of the dryer in the laundry plant has been fully considered, and the simple details have been tried to the extreme, all starting from reducing the operating cost of the user.
2. Adopt the hierarchical transmission structure , the European standard remission cone pulley with the SPA high speed belt , the transmission smooth noise is small , the maintenance is simple , the appearance is exquisite.
3. Strictly according to the national standard 1:20 volume ratio of the standard capacity of the barrel , high open hole rate cylinder , ensure that the clover full reversal space , to facilitate the combination of the grass and heat .
4. Customized multi-loop air heater to reduce heat loss and use heat efficiently . Optimization of wind tunnel design , wind volume and low noise , the air volume and evaporation area to achieve a better balance .
5. Brand motor , imported electrical drive , good load performance , high humidity , high strength is more suitable for laundry factory environment of stable operation .
- Mobile: +86-51066206136
- E-mail: info@wuxisharing.com
|
Model |
Unit |
HG-50 |
HG-100 |
|
Capacity |
Kg |
50 |
100 |
|
Volume |
L |
1000 |
2000 |
|
Drum Speed |
rpm |
45 |
32 |
|
Power Supply |
V |
220V/60Hz, 380V/50Hz,415V/50Hz |
|
|
Motor Power |
Kw |
1.1 |
2.2 |
|
Blower Power |
Kw |
1.5 |
1.5x2 |
|
Electric-heating Power |
Kw |
45 |
72 |
|
Air outlet |
mm |
ф185 |
ф200 |
|
Electric Consumption |
Kw |
2.4(Steam)/42（Electric） |
5（Steam）/70（Electric） |
|
Steam Consumption |
Kg |
70 |
120 |
|
Gas Consumption |
Kg |
2 |
3.2 |
|
Steam Pressure |
Mpa |
0.4-0.6 |
0.4-0.6 |
|
Gas Pressure |
Mpa |
0.02-0.06 |
0.02-0.06 |
|
Weight |
Kg |
700 |
1100 |
|
Dimension |
m |
1320X1620X2150 |
1620X1950X2550 |
